SF6纯度分析仪中英文版

产品简介

Product Introduction

The SF6 purity analyzer features a color LCD touch screen display, offering a user-friendly interface and ease of operation. It is equipped with imported high-precision sensors, designed for long lifespan, ensuring accurate and reproducible measurement results.

主要应用：故障定位，例行检测，气体净化，过滤监测，故障高压接点检查，SF6纯度检测。

Main Applications: Fault localization, routine testing, gas purification, filtration monitoring, high-voltage contact fault inspection, and SF6 purity detection.

产品特点

Product Features

● 4.3" TFT touch screen design

● 32-bit ARM MCU

● Separately designed air path and circuit

● Large capacity storage function

● Digital display of battery electric quantity

● Good repeatability and high response speed

● Automatic calibration of gradient

● Color LCD display

● Advanced probe protection function

● Anti-pollution and anti-disturbance capabilities

● High sensitivity and good stability

● Compact, beautiful, and easy to carry

技术参数

Technical Parameters

Measurement Range: Purity: 0 to 100%

Accuracy: Purity: ±0.5%

Resolution: Purity: 0.1%

Repeatability: Purity: ±0.5%

Pressure Range: 0 ~ 1MPa

Gas Flow Rate: 0.3 ~ 0.4L/min

Measurement Time: 5 minutes

Operating Principle: Infrared laser spectroscopic absorption principle

Operating Voltage: 110 ~ 220VAC, AC and DC dual use

Storage Temperature Rating: -25 ~ +70℃

Operating Environment: Temperature: -25 ~ +60℃

Lithium Battery: AC and DC dual-use, automatic switching, overcharge and over-discharge protection

Dimensions and Weight: 372×266.5×134.5 (mm), 3.5kg。
